High Precision LMEK8UU-25UU Flange Linear Bearings, Low Friction & High Load Capacity
Specifications
| Inner Diameter | 8, 12, 16, 20, 25 mm |
| Outer Diameter | 24, 32, 40, 47, 52 mm |
| Thickness | 19, 24, 28, 32, 35 mm |
Description
High Precision Flange Linear Bearings provide smooth and reliable linear motion for industrial applications. Available in multiple sizes (8–25 mm bore), these bearings feature a robust design with excellent load capacity and durability, ideal for automation, machinery, and precision equipment.
Basic Info.
Related Products
Specifications
| Inner Diameter | 6 mm, 8 mm, 10 mm, 12 mm, 13 mm |
| Outer Diameter | Varies by model (flanged block design) |
| Thickness | Standard for LMH series with flange |
Description
Flange bearing linear guides from IKO, LMH series (LMH6LUU to LMH13LUU), designed for CNC machines. These linear bearings feature a flange block for easy mounting and smooth motion control. Ideal for precision machinery requiring reliable linear movement.
Specifications
| Bore Diameter | 8mm, 10mm, 12mm, 15mm |
| Outer Diameter | 15mm, 18mm, 21mm, 24mm |
| Thickness | 24mm, 26mm, 28mm, 30mm |
Description
High-grade linear motion ball bearing, available in LM8UU, LM10UU, LM12UU, LM15UU models. Designed for smooth, precise linear movement with durable performance in industrial applications.
Specifications
| Bore Diameter | 3mm, 4mm, 5mm, 6mm, 8mm |
| Outer Diameter | 7mm, 9mm, 11mm, 13mm, 16mm |
| Thickness | 8mm, 9mm, 10mm, 11mm, 15mm |
| Material | Stainless Steel |
| Type | Linear Motion Bearing |
Description
Precision stainless steel linear motion bearings in standard metric sizes. Ideal for smooth linear movement in compact applications. Corrosion-resistant design ensures long service life in demanding environments.
Specifications
| Inner Diameter | 8-50mm (varies by model) |
| Outer Diameter | Varies with flange block design |
| Thickness | Standard for linear motion series |
Description
Precision flanged linear ball bearings ensure smooth, reliable linear motion. Suitable for automation, machinery, and industrial applications requiring high load capacity and durability.
Specifications
| Bore Diameter | 8mm, 10mm, 12mm |
| Outer Diameter | 15mm, 19mm, 21mm |
| Thickness | 24mm, 26mm, 28mm |
Description
Precision CNC linear slide guide bushing bearing with flange block. Compatible models: LMF8SUU, LMF8UU, LMF10UU, LMF12UU. Ideal for automation, 3D printers, and CNC machines requiring smooth linear motion. Durable construction ensures long service life under high load and speed.
Specifications
| Inner Diameter | 8 mm, 12 mm, 30 mm, 40 mm, 50 mm, 60 mm |
| Outer Diameter | 19 mm, 26 mm, 42 mm, 52 mm, 62 mm, 72 mm |
| Thickness | 24 mm, 28 mm, 37 mm, 47 mm, 57 mm, 67 mm |
Description
High-quality linear bearing with flange block, suitable for precision motion systems. Features smooth operation, durable construction, and multiple size options for versatile applications in industrial machinery and automation equipment.
Specifications
| Bore Diameter | 16 mm |
| Outer Diameter | 26 mm |
| Thickness | 20 mm |
| Material | Chrome Steel |
| Load Type | Linear Motion |
| Accuracy | High Precision |
Description
High precision CNC machined linear bearing with circular flange, designed for smooth and reliable linear motion. Ideal for industrial automation, 3D printers, and CNC machines. Features chrome steel construction for durability and consistent performance under load.
Specifications
| Inner Diameter | 8, 12, 16, 20, 25 mm |
| Outer Diameter | 24, 32, 40, 47, 52 mm |
| Thickness | 19, 24, 28, 32, 35 mm |
Description
High Precision Flange Linear Bearings provide smooth and reliable linear motion for industrial applications. Available in multiple sizes (8–25 mm bore), these bearings feature a robust design with excellent load capacity and durability, ideal for automation, machinery, and precision equipment.
Specifications
| Bore Diameter | 12 mm |
| Outer Diameter | 26 mm |
| Thickness | 20 mm |
| Flange Type | Round Flange |
| Material | Chrome Steel |
| Load Type | Radial |
Description
Precision linear bearing with round flange block for smooth radial motion. Made of durable chrome steel, it ensures high load capacity and long service life in industrial applications.
Specifications
| Bore Diameter | Inner dimension for shaft fit |
| Outer Diameter | Compact housing size |
| Thickness | Profile depth for space-limited use |
Overview
Precision IKO linear bearing designed for smooth, reliable linear motion in compact applications. Ideal for miniaturized machinery and automation systems requiring high load capacity and durability.
Product Parameters
| Model NO. | LM16UU |
| Material | Bearing Steel |
| Type | Lengthen |
| Application | Electronic Equipment, Food Machinery |
| Precision | P0 P6 P5 P4 P2 |
| Origin | Japan |
Introduction
The LM16UU linear bearing, made of high-quality Bearing Steel, features a lengthened type design with precision grades P0, P6, P5, P4, P2. Originating from Japan, it is ideal for Electronic Equipment and Food Machinery, ensuring reliable performance in various industrial applications.
Specifications
| Inner Diameter | 50mm / 60mm |
| Outer Diameter | Standard Flange Mount |
| Thickness | Compact Design |
Description
High-performance linear motion slide unit with integrated ball bearing and flange block. Designed for smooth, precise movement in automotive and industrial applications. Offers durability, low friction, and easy installation for reliable linear guidance.
